SparkFun's Snappable Protoboard board outline: 129.54 by 68.58 mm with no plated holes, traced from the Eagle board file SparkFun publish for product 13268.
- Made by
SparkFun- SKU
- 13268
- Kind
- Circuit board (PCB)
- Licence
- CC-BY-SA-4.0
- Keywords
- board, pcb, snappable, sparkfun, prototyping
| Overall size (X × Y × Z) | 129.5 × 68.6 × 1.7 mm |
|---|---|
| PCB size | 129.5 × 68.6 mm |
| PCB thickness | 1.6 mm |
| Through-hole pads | 1250 |
| Function | prototyping board |
| Form factor | board |
