PN Beslag's 4" butt hinge, zinc-plated for indoors: two 1.5 mm leaves 101 mm long and 70 mm across opened flat, five knuckles on a 6.5 mm pin, four countersunk holes a leaf for 4.5 mm screws, staggered. The hole positions are scaled from PN's drawing, not stated by PN. Sold singly by BAUHAUS (1060956) and as a pair by Silvan (2836856, PN 150502301).
- Made by
- PN Beslag
- Modelled by
- ReDo.Pro
- SKU
- 150502307
- Kind
- Parametric part
- Licence
- CC-BY-SA-4.0
- Keywords
- hinge, butt hinge, kanthængsel, hængsel, door, cabinet, pn beslag, 101
| Overall size (X × Y × Z) | 70 × 101 × 9.5 mm |
|---|---|
| Volume | 16 cm³ |
| Type | butt hinge |
| Material | zinc-plated steel |
| Pin | 6.5 mm |
| Screw | 4.5 mm |
| EAN | 5701984104856 |
| BAUHAUS item | 1060956 |
| Silvan item | 2836856 |
