Every deep-groove ball bearing the Inventory carries behind one tile: pick the part number and the bore, outside diameter and width come with it.
- Made by
FreeCAD Library- Kind
- 3D model
- Licence
- CC-BY-3.0
- Keywords
- bearing, ball bearing, deep groove, radial, 608, 623, 624, 6201, 6803, f623, flanged, shaft, rotation
| Overall size (X × Y × Z) | 22 × 22 × 7 mm |
|---|---|
| Type | deep groove radial |
| Load rating | 3700 N dynamic, 1400 N static |
| Weight | 12 g |
| Width | 7 mm |
| Outside diameter | 22 mm |
| Bore | 8 mm |
