SparkFun's SSOP-20 DIP Adapter board outline: 20.32 by 25.40 mm with no plated holes, traced from the Eagle board file SparkFun publish for product 499.
One of the SparkFun DIP Adapter family.
- Made by
SparkFun- SKU
- 499
- Kind
- Circuit board (PCB)
- Licence
- CC-BY-SA-4.0
- Keywords
- adapter, board, pcb, sparkfun, ssop20
| Overall size (X × Y × Z) | 20.3 × 25.4 × 1.7 mm |
|---|---|
| PCB size | 20.3 × 25.4 mm |
| PCB thickness | 1.6 mm |
| Through-hole pads | 20 |
| Function | SSOP to DIP adapter |
| Form factor | board |
| Status | discontinued |
