The one-sided horn for CyberBrick's 9 g servo: a 7.3 mm hub with a 4.9 mm bore for the spline and a 2.5 mm screw hole, and one 14 mm arm with 1 mm holes at 2 mm pitch. Paint it from the Material panel: the horn is one moulding, so the whole arm takes the colour.
One of the Servo Arm family.
- Made by
CyberBrick- Kind
- 3D model
- Licence
- LicenseRef-CyberBrick-CAD
- Keywords
- cyberbrick, pg002-half-arm, servo, horn, arm, single, pg001
| Overall size (X × Y × Z) | 19.7 × 7.3 × 4.2 mm |
|---|---|
| Model | PG002-half-arm |
