The fourteen-pin AVR: twelve I/O, eight of them analog inputs, in the same family as the ATtiny85. Arduino numbers on the labels are ATTinyCore's counter-clockwise mapping, which is that core's default for this chip.
- Made by
- Microchip
- Kind
- Parametric part
- Licence
- CC-BY-SA-4.0
- Keywords
- attiny84, attiny, avr, microcontroller, mcu, arduino, 14-pin, dip, chip, breadboard
| Overall size (X × Y × Z) | 19.1 × 7.9 × 7 mm |
|---|---|
| Volume | 414 mm³ |
| Type | microcontroller |
| Chip | ATtiny84 |
| Clock speed | 20 MHz |
| Flash | 8 KB |
| RAM | 512 B SRAM |
| GPIO pins | 12 |
| Interface | USI |
| Logic level | 2.7-5.5 V |
| Resolution | 10 bit |
| Package | DIP-14 |
