A HIWIN MG miniature profile rail cut to any length: the narrow MGN5, MGN7, MGN9, MGN12 and MGN15 or the wide MGW7, MGW9, MGW12 and MGW15, at HIWIN's section, with counterbored screw holes at the series' pitch, two rows of them on the MGW15. With no end distance given it is drilled the way HIWIN cuts a rail, symmetric and as many holes as fit their minimum end distance; an end distance E1 starts the holes that far from its -Y end instead.

Made by

ReDo.Pro

Kind

Parametric part

Licence

CC-BY-SA-4.0

Keywords

linear guide, rail, profile rail, mgn, mgn5, mgn7, mgn9, mgn12, mgn15, mgw, mgw7, mgw9, mgw12, mgw15, wide, hiwin, linear motion, slide, cut to length, end distance
