Adafruit's TFT Bonnet: a colour display and buttons for a Raspberry Pi, on the Micro HAT outline and hole pattern.
One of the Pi HAT family.
- Made by
Adafruit- SKU
- 4506
- Kind
- Circuit board (PCB)
- Licence
- CC-BY-SA-3.0
- Keywords
- adafruit, bonnet, colour, display, raspberry pi, screen, tft, st7789, 240x240, hat, rpi, color, ips
| Overall size (X × Y × Z) | 65 × 30.7 × 20 mm |
|---|---|
| PCB size | 65 × 30.7 mm |
| PCB thickness | 1.6 mm |
| Mounting holes | 4 × Ø2.8 mm |
| Components | 20 |
| Function | display |
| Form factor | hat |
| Chip | ST7789 |
| Interface | SPI |
| Logic level | 3.3 V |
| Resolution | 240 x 240 |
| Display | 1.3 in IPS TFT |
| Weight | 13 g |
| Qty | Part | Value | References | Datasheet |
|---|---|---|---|---|
| × 8 | SMD Resistor0805 | 10K | R1, R3, R11, R12, R13, R14, R16, R18 | RC_L series datasheet (Yageo) |
| × 2 | SMD Capacitor0805 | 10uF | C1, C10 | X7R SMD MLCC series datasheet (KEMET) |
| × 2 | SMD Tactile SwitchEVQP0 | EVQQ | SW1, SW2 | EVQP0 datasheet (Panasonic) |
| × 1 | 5-Way Navigation Switch, Alps SKQUBA | NAVSWITCHSKQUABAUE010 | SW3 | SKQU datasheet (Alps Alpine) |
| × 1 | Headerfemale · 20 · 2 · smd | RASPBERRYPI_BPLUS_BONNETSMT | RPI1 | |
| × 1 | SMD Resistor0603 | 10 | R5 | RC_L series datasheet (Yageo) |
| × 1 | SMD Resistor0603 | 10K | R2 | RC_L series datasheet (Yageo) |
| × 1 | SOTSOT-23-3 | APX803 | IC1 | APX803 datasheet (Diodes Incorporated) |
| × 1 | SOTSOT-23W | BSS138 | Q3 | BSS138 datasheet (Diodes Incorporated) |
| × 1 | TFT Display, 1.3" 240 x 240 | DISP_LCD_ST7789_1.3IN | DISPLAY1 | ST7789VW datasheet (Sitronix) |
| × 1 | Wire-to-Board ConnectorSH side entry · 4 | STEMMA_I2C_QT | CONN1 | JST SH datasheet (JST) |
