An LM10UU linear ball bushing: 10 mm shaft, 19 mm outside, 29 mm long. Runs along a smooth rod rather than turning on it.
One of the Linear Bearing family.
- Made by
FreeCAD Library- Kind
- 3D model
- Licence
- CC-BY-3.0
- Keywords
- bearing, linear bearing, ball bushing, lm10uu, lm, 10 mm shaft, rod, linear motion, slide
| Overall size (X × Y × Z) | 19 × 19 × 29 mm |
|---|---|
| Type | linear ball bushing |
| Load rating | 373 N dynamic, 549 N static |
| Weight | 25 g |
| Length | 29 mm |
| Outside diameter | 19 mm |
| Bore | 10 mm |
