LIS3DH Accelerometer

Adafruit's LIS3DH triple-axis accelerometer. An older breakout than the STEMMA QT boards: it stands portrait, with a 6-way header column down each long edge.

One of the IMU Board family.

Made by
Adafruit
SKU
2809
Kind
Circuit board (PCB)
Licence
CC-BY-SA-3.0
Keywords
lis3dh, accelerometer, motion, tilt, sensor, breakout, i2c, spi
Overall size (X × Y × Z)17.8 × 25.4 × 4.6 mm
PCB size17.8 × 25.4 mm
PCB thickness1.6 mm
Mounting holes4 × Ø2.5 mm
Through-hole pads12
Components12
Functionmotion sensor
ChipLIS3DH
InterfaceI2C, SPI
Logic level3.3-5 V
Resolution10 bit
Range±2/±4/±8/±16 g
Weight1.5 g
