6 DOF IMU Sensor

Gravity: 6 DOF IMU Sensor — DFRobot SEN0692.

One of the IMU Board family.

Made by
DFRobot
SKU
SEN0692
Kind
Circuit board (PCB)
Licence
LicenseRef-DFRobot-CAD
Keywords
dfrobot, sen0692, gravity, dof, imu, sensor, accelerometer, gyroscope, bmi323, i2c, uart, 6-axis
Overall size (X × Y × Z)32 × 27 × 8.3 mm
PCB size32 × 27 mm
PCB thickness1.6 mm
Mounting holes2 × Ø3.2 mm
Through-hole pads6
Components29
FunctionIMU
ChipBMI323
InterfaceI2C, UART
Supply voltage3.3-5 V
Current3.1 mA
Resolution16 bit
Range±2 to ±16 g, ±125 to ±2000 °/s
